D2 Tool Steel | DIN 1.2379 | X153CrMo12 | SKD11 | Superior
- Description
- Size Guide
Description
D2 Tool Steel | DIN 1.2379 | X153CrMo12 | SKD11 price in India.
D2 Tool Steel (DIN 1.2379 | X153CrMo12 | SKD11) is best for making sheet metal cutting tools.
We have been a professional sheet metal cutting tools steel grade D2 tool steel supplier for over five decades.
Our company “Jai Ganesh steel company” has a sales tax number since1982.
We supply AISI / ASTM A681 cold works DIN 1.2379 tool steel alloy steel materials in reliable quality and for an attractive price for sale.
We have deep knowledge of D2 tool steel’s chemical composition and properties.
Contact us for any D2 Tool Steel, DIN 1.2379, X153CrMo12, and SKD11 materials requirements.
Cold Works DIN 1.2379 is a high carbon, high chromium tool steel (12% chrome) with extremely high wear-resisting properties, heat treatable to 60-62 HRC.
D2 steel is very wear-resistant but not as tough as lower alloyed steel.
D2 tool steel hardens in air with a low order of movement and offers a measure of corrosion resistance when polished.
The high percentage of chromium gives it mild corrosion-resisting properties in the hardened condition. The mechanical properties of D2 are very sensitive to heat treatment.
D2 steel is available in de-carb-free rounds, flats, and squares, as well as ground flat stock and drill rods.
D2 Tool Steel most common Material Application.
AISI grade DIN 1.2379 tool steels are used for long-run tooling applications.
best for tooling applications where wear resistance is important.
such as blanking or forming dies and thread rolling dies.
D2 steel has a hardness in the range of 55 to 62 HRC, which makes it a very durable and high-end knife steel.
D2 steel will keep its hardness up to a temperature of 425 °C (797 °F).
Some main applications for D2 tool steel are as below:
Blanking Dies.
Forming Dies.
Coining Dies.
Slitting Cutters.
Heading Tools.
Long Punches.
Forming Rolls.
Edging Rolls.
Master Tools.
Beading Rolls.
Intricate Punches.
Extrusion Dies.
Drawing Dies.
Lamination Dies.
Thread Rolling Dies.
Shear Blades.
Burnishing Tools.
Gauges.
Knurls.
Wear Parts.
We usually hold DIN 1.2379 tool steel on sale activities, and you would have our price on a regular schedule.
Contact us and sign in to our newsletter to have the DIN 1.2379 tool steel materials price list and commercial quote today.
Because of its popularity as tool steel, it was only a matter of time before someone used D2.
D2 steel relatively high wear resistance, along with good hardness and toughness, made it work well as a knife steel.
We have a wide range of plastic mold steel.
D2 steel is an air-hardening, high-carbon, high-chromium tool steel.
It has high wear and abrasion-resistant properties.
Find D2 Tool Steel/ DIN 1.2379 / X153CrMo12 / SKD11 Steel Chemical compositions.
The typical chemical compositions difference between D2 STEEL, HCHCR STEEL, DIN 1.2379, and SKD11 Tool Steel material.
| GRADE NAME | C % | SI % | Cr % | Mn % | Mo % | V % | S % | P % | Cu % | Ni% |
|---|---|---|---|---|---|---|---|---|---|---|
| AISI D2 Tool Steel | 2.00% ~ 2.35% | 0.10～0.60 | 11.0～13.0 | 0.20～0.60 | 0.70～1.20 | 0.50～1.10 | ≤0.030 | ≤0.030 | ||
| AISI D3 Tool Steel | 2.00～2.35 | 0.10～0.60 | 11.0～13.5 | 0.20～0.60 | ~ | ~ | ≤0.030 | ≤0.030 | ||
| HCRCR STEEL | 2.00～2.35 | 0.10～0.60 | 11.0～13.5 | 0.20～0.60 | ~ | ~ | ≤0.030 | ≤0.030 | ||
| SKD11 Tool Steel | 1.40～1.60 | ≤0.40 | 11.0～13.0 | ≤0.60 | 0.80～1.20 | 0.20～0.50 | ≤0.030 | ≤0.030 | ||
| DIN 1.2379 | 1.45 ~ 1.60 | 0.1 ~ 0.60 | 11.0～13.0 | 0.20 ~ 0.60 | 0.70 ~ 1.0 | 0.70 ~ 1.0 | ≤0.030 | ≤0.030 | ||
| DIN X155CrMoV12-1 | 1.40 ~ 1.60 | ≤0.40 | 11.0～12.0 | 0.20 ~ 0.60 | 0.60 ~ 0.80 | 0.90 ~ 1.10 | ≤0.030 | ≤0.030 | ||
| DIN X165CrMoV12 | 1.55 ~ 1.75 | 0.20～0.40 | 11.0～12.0 | 0.20 ~ 0.60 | 0.40 ~ 0.60 | 0.10 ~ 0.50 | ≤0.030 | ≤0.030 | ||
| X160CrMoV12 | 1.45 ~ 1.70 | 0.10～0.40 | 11.0～13.0 | 0.15 ~ 0.45 | 0.70 ~ 1.10 | 0.70 ~ 1.0 | ≤0.030 | ≤0.030 | ||
| Z160CDV12 | 1.45 ~ 1.70 | 0.10～0.40 | 11.0～13.0 | 0.15 ~ 0.45 | 0.70 ~ 1.10 | 0.70 ~ 1.0 | ≤0.030 | ≤0.030 | ||
| Cr12MoV (CHINA) | 1.45 ~ 1.70 | 0.10～0.40 | 11.0～12.50 | 0.10 ~ 0.40 | 0.40 ~ 0.60 | 0.15 ~ 0.30 | ≤0.030 | ≤0.030 | ≤0.030 | ≤0.020 |
| UNS T30402 | 1.50 ~ 1.60 | 0.10～0.40 | 11.0～12.0 | 0.15 ~ 0.45 | 0.60 ~ 1.20 | 0.90 ~ 1.10 | ≤0.030 | ≤0.030 | ||
| SIHARD 2379 | 1.55 | 0.35 | 12 | 0.40 | 0.70 | 0.85 | ≤0.030 | ≤0.030 |
H13 tool Steel is Best for making hot work tooling.
